THUMUP ENGINEERING

Items

Specifications

Main unit

2 line x 20 character LCD with backlight

Working temperature: -25--60℃

Mini thermal printer with 24 line character output

4x4+2 pushbutton keypad

RS-485 interface for networking

Signal input & output

1 channel 4-20mA output

1channel OCT output

1channel relay output

3 channel 4-20mA input

Medium

Water (hot water, chilled water, city water, sea water, waste water, etc.);

Sewage with small particle content;

Oil (crude oil, lubricating oil, diesel oil, fuel oil, etc.);  Chemicals (alcohol, acids, etc.);

Plant effluent; Beverage,

liquid food; Ultra-pure liquids; Solvents and other liquids

Flow rate Range

0~±10m/s

Accuracy

Better than ±1%

Battery

Built-in rechargeable Ni-MH rechargeable battery, provide over 20 hours of continuous operation

Power Consumption

1.5W

Power supply

Built-in rechargeable Ni-MH battery (for 20 hours operation) or AC 220V

Weight & Dimensions

2.5kg ;  225*180*67mm:

Remarks

With a high strength carrying case suitable for normal and harsh environment
