SUP-TDS-6011  Conductivity Sensor

Features

1. A variety of intelligent equipment matching.

2. Intelligent temperature compensation design: Instrument integrated automatic, manual dual temperature compensation mode Support NTC10K temperature compensation components, suitable for a variety of measurement occasions, temperature compensation type a key adjustable.

3. A variety of functions in one: US control conductivity EC / TDS measurement capabilities to achieve two in one, cost-effective integrated design to support the boiler water, RO water treatment, sewage treatment, pharmaceutical industry and other liquid measurement and monitoring.

Conductivity cell model	CON2136-13	CON1134-13	CON3133-13
Conductivity cell constant	250px-1	25px-1	2.5px-1
Measuring range	(0.5~10)mS/cm	(1.0~2000)μS/cm	(0.5~200)μS/cm
Application	Sewage detection	River, raw water testing	Drinking water and other testing
Measurement parameters	Measuring range	Resolution	Accuracy
Conductivity	0.05μS/cm~20.00mS/cm	0.01μS/cm	1.5 level
Resistivity	0.05MΩ·cm~18.25MΩ·cm	0.01MΩ·cm	2.0 level
TDS	0.25ppm~10.00ppm	0.01ppm	1.5 level
temperature range	(0~50)℃	0.1℃	± 0.5 degrees Celsius



Wiring Method

Instrument Selection
