Measurement range

DO：0-20 mg/L、0-20 ppm；

Temperature：0-45℃

Measurement Accuracy

DO:±3% of  the measured value；  Temperature：±0.5℃

Pressure range

≤0.3Mpa

Calibration

Air automated calibration,sample calibration

Main material

Body：SUS316L + PVC（fresh water），Titanium alloy（marine）；O-ring：fluorine rubber；Cable：PVC

Power supply

AC：100-240VAC (50/60HZ)

DC：9~36VDC

Output

2-way 4-20mA

Relay

Setting three-way relays,programmed response parameter and response value.

Communication protocol

MODBUS  RS485

Storage temperature

-15-65℃

Measuring temperature

0-45℃

Dimensions

Sensor：Dia55mm*L 342mm

Transmitter：145*125*162mm(L*W*H)

Weight

Sensor：1.85KG；Transmitter：1.35KG

Protective rate

Sensor：IP68/NEMA6P；Transmitter：IP65/ NEMA4X

Cable length

Standard:10m, the maximum may be extended to 100m
